GOKU GN 413 13A AIO V2.1 (MPU6000) 25.5X25.5


Price:
$64.99
Stock:
Sold out
  • Description
  • Reviews
  • Description
  • INAV Firmware Download

    Wiring Diagram

    The Flywoo GOKU GN413S AIO Toothpick FC is a specially customized for your toothpick builds! This FC is super light, weighs only 6g, comes with 2-4S input voltage, and has a 13A ESC continuous current.

    Specifications

    GOKU GN413S AIO Toothpick FC

    • MCU: STM32F411
    • IMU: MPU6000 gyro/accelerometer (SPI)
    • OSD: BetaFlight OSD w/ AT7456E chip
    • black box: 8M
    • LED:4*WS2812
    • BEC Output: 5V@2A
    • Integrated LC Filter
    • Barometer:No
    • Firmware target: FLYWOOF411

    13A 4in1 ESC

    • ESC MCU: BB21F16G
    • Continuous current: 13A
    • Input:2-4s lipo
    • Supports Dshot600 ,Oneshot,Multishot
    • Size: 34×34mm board,25.5mm mounting holes (M2)
    • Weight: 6g
  • Reviews
  • Customer Reviews

    Based on 14 reviews
    93%
    (13)
    7%
    (1)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    J
    Jonathan Covert
    Rad aio!

    Love it, please restock and I’ll buy 5 more. Leds on this one are really nice too!

    k
    kartik pillai
    Best FC and services by flywoo

    I am still experiencing the use of FC and so far it's working fine. Apart from product review and I would like to recommend Flywoo for best service to fulfill it's customer and also aftersale service is ACE. Much appreciated for your service!!!

    d
    dinosarus
    Great AIO

    I've been flying this on a 2S whoop with 1103 motors and 1.6in props for a couple of months. As some other reviews say the UART pads are quite small, although the motor pads are fine - that’s what you get with most AIO boards. The board works great though, no issues running on betaflght 4.3 RC3 and Bluejay 0.16.

    C
    Customer
    The board is great and the best

    The board is great and the best but the vtx pads are very small and get shorted easily .Even though The CTC works fine but I suggest that the pin head should be used instead of soldering the Btc wires to the Flight controller. Overall a best board

    T
    Tyrone Lawson
    Great FC

    This the perfect FC for Primo and whoop builds
